PVC Shrink Blown Film Extrusion
PVC Shrink Film Blowing Machine Produce PVC shrink film,to pack paper tissue,Battery,bottle,wire,books.
Inquiry Basket
OEM：
Available
Sample：
Available
Port：
Ningbo
Payment：
PayPal,VISA,MasterCard,Western Union,L/C,T/T
Place of Origin：
China
Shipping：
Sea freight · Land freight · Air freight
Supply Ability：
300 unit per Year
Product Details
PVC Shrink Blown Film Extrusion
The equipment employed in PVC Shrink Blown Film Extrusion incorporates advanced features such as a rotary die head, frequency conversion speed regulation, and automatic temperature control. The finished products demonstrate superior plasticization, adhering to stringent criteria for film thickness consistency, transparency, flatness, shrinkage, and other quality metrics similar to those necessary for printing on thin films.
The plastic film blowing machine is designed with a compact and user-friendly structure. It consists of key components, including an extruder, rotary die head, cooling air ring, initial traction unit, hot water tank, calibrator, secondary traction with electric lift, double station coiler, extruder electric control cabinet, and auxiliary machine electric control cabinet.
The PVC Shrink Blown Film Extrusion equipment is specifically engineered to create heat-shrinkable films from PVC plastic resin utilizing the blown film extrusion technique.
The blown film extrusion process produces PVC shrink blown films that provide outstanding transparency, gloss, and significant shrinkage characteristics. As a result, these films are widely favored in contemporary packaging solutions across a range of sectors, such as food, beverages, teas, glassware, handicrafts, sanitary items, cosmetics, and electronics.
PVC hot shrink film
|
Item |
SJ-P600 |
SJ-P800 |
SJ-P1000 |
|
Film width |
300-600mm |
500-800mm |
700-1000mm |
|
Film thickness |
0.02-0.08mm |
0.02-0.09mm |
0.25-0.10mm |
|
Capacity |
40kg |
50kg |
60kg |
|
Lateral shrinkage |
45-50% |
45-50% |
45-50% |
|
longitudinal shrinkage |
5-25% |
5-25% |
5-25% |
|
Screw diameter |
60mm |
65mm |
70mm |
|
Screw ratio |
26:1 |
26:1 |
26:1 |
|
Motor |
15kw |
18.5kw |
22kw |
|
Heater |
10kw |
13kw |
16kw |
|
traction speed |
5-40m/min |
5-40m/min |
5-40m/min |
|
Machine weigth |
2200kg |
2500kg |
3000kg |
|
Power |
220V,380V,440V,480V(Customized based on request,For example: USA 480V 60Hz, Mexico 440V/220V 60Hz, Saudi Arabia 380V 60Hz, Nigeria 415V 50Hz…) |
||
|
Machine size(cm) |
550*200*320 |
600*220*360 |
650*250*400 |
※Correct specifications depend on the actual model. All specifications are subject to change without prior notice.
Shipment
shipment of plastic bag machine
If you only buy one machine,we will pack machine with wooden pack,and loading container with Less Than Container Load（LCL）.
If you buy one container machines,we will pack machine with stretch film and loading container directly (FCL full container load).
instalment service
install machines in customer factory
Machine parts supplier
Our Main parts cooperator as following brand,but standard parts all made from China.
Material supplier
How To Find Polyethelene For Blown Film Extrusion.
Extrusion Film Extrusion use Polyethelene,such as
Low Density Polyethylene(LDPE),High Density Polyethylene(HDPE) and Linear Low Density Polyethylene(LLDPE),Polypropylene(PP).
Below are big brand material supplier in the world,they open office all over the world,you can check them in local market.
1.Sabic Saudi Basic Industries Corporation
2.ExxonMobil Chemical Company
3.Dow Chemical Company
